To install OpenWrt build system to create antenna firmware we need to install prerequise

sudo apt-get update
sudo apt-get install build-essential subversion mercurial git-core libncurses5-dev zlib1g-dev gawk flex quilt libssl-dev xsltproc libxml-parser-perl unzip

Clone the latest stable version of the git repository of OpenWrt (this creates a directory ‘openwrt’, which is the OpenWrt build system build-directory) in our case Chaos Calmer

git clone git://git.openwrt.org/15.05/openwrt.git

Download and install all available “feeds”

cd openwrt
./scripts/feeds update -a
./scripts/feeds install bmon
./scripts/feeds install coova-chilli
./scripts/feeds install curl
./scripts/feeds install git
./scripts/feeds install htop
./scripts/feeds install iwinfo
./scripts/feeds install luasocket
./scripts/feeds install libuci-lua
./scripts/feeds install netperf
./scripts/feeds install -a -p routing
./scripts/feeds install tinyproxy
./scripts/feeds install wget

Have a bug need to be fix with the package of coova-chilli (solved in the future release Bleeding Edge), you need to edit the file package/feeds/packages/coova-chilli/Makefile like this:

# around line 138 you have:
$(INSTALL_DIR) $(1)/usr/lib/iptables \
$(CP) $(PKG_INSTALL_DIR)/usr/lib/iptables/lib*.so $(1)/usr/lib/iptables/; \

#Add the condition to fix:
$(if $(CONFIG_PACKAGE_kmod-ipt-coova), \
   $(INSTALL_DIR) $(1)/usr/lib/iptables; \
   $(CP) $(PKG_INSTALL_DIR)/usr/lib/iptables/lib*.so $(1)/usr/lib/iptables/; \
)

Working with Feeds, The list of usable feeds is configured from the feeds.conf file (or feeds.conf.default) and for list available pas

./scripts/feeds list

Make OpenWrt build system check for missing package and launch the menu to select package

make defconfig
make prereq
make menuconfig

For specific configuration need to create a folder files in openwrt directory and put inside your config (like /etc/config/firewall)

Launch the build of the firmware:

make V=99

To put the firmware on the antenna you can use one of the method below

  1. By tftp: put the antenna in tftp mode and use a freeware like pumpkins to put the firmware
  2. By sysupgrade: if you have already openwrt on and you want to keep the config in ssh on antenna do a sysupgrade -v /tmp/openwrt-ar71xx-xxxxxxxx.bin
  3. By mtd: if you want a clean system use in ssh the command mtd -r write /tmp/openwrt-ar71xx-xxxxxxxx.bin firmware
